PC-24 – Technische Daten

2 12" Primary flight display flat panel units

Smartview synthetic vision system on each primary flight display

2 Primary flight display controllers

1 Integrated global navigation system sensor unit with satellite-based augmentation system receiver

2 Audio/marker panels

1 Dual channel autopilot with dual yaw damper

1 Flight guidance panel

2 12" Multi-function display flat panel units

1 Touch screen controller

1 Cursor control device

Switch panels

2 Mode S diversity transponders with Automatic Dependent Surveillance – Broadcast (ADS-B) OUT functionality

2 Multi-mode digital radios

2 Attitude reference systems comprising of 1 inertial reference system and 1 attitude heading reference system and magnetometer

1 Distance measuring equipment

1 Radar altimeter

1 Integrated enhanced ground proximity warning system class B

Traffic Collision Avoidance System (TCAS) I

Autothrottle system

Tactile feedback (roll and pitch)

Automatic yaw trim

Dual Flight Management System (FMS)

Localizer Performance with Vertical Guidance (LPV) approach capability

Required Navigation Performance (RNP) 0.3 capability

Utilities management system

Dual pitot-static systems

Dual angle of attack sensors

1 Required Navigation Performance 2100 weather radar

Radar Altimeter 5G Filter to operate safely within the 5G environment

1 Electronic standby instrument system with dedicated pitot-static system and magnetometer

1 Emergency Local Transmitter (ELT) 406 MHz with remote switch, global positioning system and navigation interface

1 Flight time recorder (Hobbs meter)

1 Lightweight data recorder

1 Lightweight data recorder

2 Crew control yokes

2 Rudder pedal sets including brake pedals

2 Crew seats: adjustable, reclining with foldable armrest, headrest, upholstery, 4-point torso restraint system and life vest storage

Storage compartments, suitable for storing aeronautical handbooks and/or tablets

2 Cockpit speakers

1 Handheld microphone

2 Active noise reduction headsets with microphones

Cockpit roof, side walls, console panels finished in aviation standard leather, ultra-leather, fabric or paint

Floor carpet

1 Cockpit/cabin bulkhead divider with curtain

2 Adjustable sun visors

2 Cup holders each side

Notepad, pen holders

2 USB charging outlets (1 on each side)

1 LED dome light

5 LED flood lights for instrument and side panels

2 LED map reading lights
